Analog Devices ADIS16488 MEMS IMU with Built-In Gyroscope Accelerometer and Magnetometer

Brand Name : Firepower

Model Number : 16488HA

Certification : Military standard

Place of Origin : China

MOQ : 1

Price : negotiable

Payment Terms : T/T

Supply Ability : 50/month

Delivery Time : 20 days for sample

Packaging Details : sponge+ box

Range : ±450°/s

Bias Instability : ≤0.15º/h

Random Walk Cefficient : ≤0.15°/√h

Scale Factor Nolinearity : ≤100ppm

Bandwidth : 250Hz

Resolution : 2º/h

Contact Now

Analog Devices ADIS16488 MEMS IMU with Built-In Gyroscope Accelerometer and Magnetometer

The ADIS16488HA is a high-performance MEMS IMU integrating a three-axis gyroscope and accelerometer, capable of ±450°/s angular rate and ±20 g acceleration measurements. Featuring 0.3°/h gyro zero-bias instability, 0.25 mg accelerometer bias, low random walk, and high linearity, it delivers precise inertial data. Full compensation for temperature (-45~85 °C), installation misalignment, and nonlinearities ensures accurate and stable performance. SPI communication at 8-15 MHz, 1.5 W power, 250 Hz bandwidth, and 0.1 % cross-coupling make it perfect for UAVs, robotics, autonomous vehicles, industrial automation, and mobile mapping applications.

Technical Specifications
Parameter Test conditions Minimum value Typical value Maximum value Unit
Gyroscope
Dynamic measuring range ±450 º/s
Zero-bias instability Allan variance, better than 0.3 º/h
Zero bias stability 10s smooth, RMS, better than 3 º/h
Zero bias in full temperature range -40 ℃ ~ 85 ℃, 10 s smooth, rms 20 º/h
Random walk 1σ 0.15 º/√h
Zero-bias repeatability 1σ 5 º/h
Scale factor repeatability 1σ 100 ppm
Scale factor nonlinearity 1σ 100 ppm
Bandwidth (-3dB) 250 Hz
Cross coupling 0.1 %
Resolution 2 º/h
Acceleration sensitivity 2 °/h/g
Accelerometer
Dynamic measuring range ±20 g
Zero bias stability Allan variance 0.07 mg
Zero bias in full temperature range -40 ℃ ~ 85 ℃, 10 s smooth, rms 3 mg
Zero bias stability 10s smooth, RMS, better than 0.25 mg
Random walk 1σ 0.029 m/s/√h
Zero-bias repeatability 1σ 0.5 mg
Scale factor repeatability 1σ 500 ppm
Scale factor nonlinearity FS=20g 500 ppm
Bandwidth (-3dB) 250 Hz
Cross coupling 0.1 %
Communication Interface
1-way SPI Enter the clock frequency 8 15 MHz
Electrical characteristics
Voltage Direct current 3.3 V
Power consumption 1.5 1.5 W
Ripple P-P 48±2 100 mV
Use environment
Operating temperature -45 85 ℃
Storage temperature -55 85 ℃
Product Diagrams
Analog Devices ADIS16488 MEMS IMU with Built-In Gyroscope Accelerometer and Magnetometer
Outline Drawing
Analog Devices ADIS16488 MEMS IMU with Built-In Gyroscope Accelerometer and Magnetometer
Connector Diagram
Analog Devices ADIS16488 MEMS IMU with Built-In Gyroscope Accelerometer and Magnetometer
Axial Direction Diagram
